Specification
Item | Content |
---|---|
Capacity | 350~1500g |
Roasting System | Hybrid (Half Hot Air) |
Fuel Source | GAS (LPG or LNG) |
Burner | Pilot burner with low gas consumption |
Isolate Layer | No-asbestos fiber |
Gas Delivery System | Gas detection prior to ignition |
Bin Protector | Thermostat with digital setting alarm |
Flow Volume Control | Step-less adjustable control |
Material of Drum | Stainless double-walled inner (SUS 304) |
Cooling Tanker | Anti-pinching rotary mixer |
Cooling Blower | Independent cooling blower |
Temp. Display | 4 Digit display with decimal |
Driven | AC motor with reduce gear |
Voltage | 110V/220V |
Frequency | Single Phase 50/60 HZ |
Illumination | LED |
Paint Coat | RoHS Compliant |
Data Logger Supported | Artisan or Cropster (USB or Bluetooth) |
Dimension & Weight
Roaster Device | |
---|---|
Dimension (W x L x H) | 1200 x 580 x 900 (mm) |
Weight | 120 Kgs |
Cyclone System | |
---|---|
Dimension (W x L x H) | 400 x 400 x 1110 (mm) |
Weight | 15 Kgs |
Options for K1.0
![Options for K1.0](https://www.kapokcoffee.com/wp-content/uploads/2021/06/roaster_K1.0b.jpg)
Inlet Air Temperature Display
Heat energy indicating.
![Options for K1.0](https://www.kapokcoffee.com/wp-content/uploads/2021/06/roaster_K1.0c.jpg)
Increase Cooling Crown
More space for beans.
![Options for K1.0](https://www.kapokcoffee.com/wp-content/uploads/2021/06/roaster_K1.0d.jpg)
Differential Pressure Gauge
Extra gauge provide more pressure data.
![Options for K500](https://www.kapokcoffee.com/wp-content/uploads/2021/06/roaster_K500-2.jpg)
Adjustable Inner Drum Speed
Changeable drum speed, provide more styleâs roasting.
